Gain

22 dB

Inputs

• 3 sets RCA line input
• 2 sets balanced/RCA selectable inputs
• 1 set RCA tape monitor input
• 1 set RCA cinema bypass input
• Optional MM phono and MC (or additional line input if phono is not fitted)

Outputs

2 sets balanced
2 sets single-ended

Tubes

2x 12AU7

4x 12AX7

Absolue Phase

Correct from all inputs to all outputs

Frequency Response

Flat over audio band -3 db bandwidth 4 Hz - 200 kHz

THD

Approx. .04%

Maximum Output

30 volts RMS single-ended; >30 volts RMS-balanced

Output Impedance

Via RCA jacks: 300 ohms; inverting from all sources to RCA main outputs only
Via XLR connector: 600 ohms with positive phase on pin 2, negative phase on pin 3 (“pin 2 hot” EIA / RCA standard)

Maximum Input

Infinite signal (attenuation precedes the gain circuitry)

Recommended Output Load

> 10000 ohms

Power

External power supply, detachable umbilical cable, detachable IEC power cord

Tape Output

Unity gain from selector, non-inverting for archival integrity

Cinema Bypass

Yes

Voltage

May be ordered for 100v, 120v, 220v, or 230/240v operation

Remote Control

Included

Illumination

Illuminated logo may be switched off

Finish

Hand-rubbed gold-flake gloss black lacquer with chrome knobs standard.

Hand-rubbed metallic gloss silver lacquer with chrome knobs special order with additional cost.

Warranty

Two years parts and labor, excluding tubes (USA, see manual for full details)

Dimensions (H x W x D)

Audio chassis (including knobs and connectors): 5.5 x 17.9 x 15.3 in. (14 x 45.5 x 38.9 cm.)

Power supply (not including cables and cable clamp): 4.75 x 6.75 x 14 in. (12.1 x 17.1 x 35.6 cm.)

Shipping Weight

Audio chassis: 40 lbs. (18.2 kg.)

Tubes

3x 12AX7

Gain

462 dB MC, 42 dB MM (measured at tape output)

Frequency Response

RIAA +/- .25 dB

Channel Seperation

> 70dB @ 1 kHz

Maximum Input

Infinite signal (attenuation precedes the gain circuitry)

MC Load Impedance

selectable, 470, 300, 250, 200, 150, and 100 ohms

MM Load Impedance

selectable, 47k, 30k, 25k, 15k, and 10k ohms
100pF

Overload

117MV @ 1kHz = 8 volts RMS output; 460MV @ 10kHz

Residual Noise

Less than 3MV at output (s/n ratio greater than approx. 69db

Tubes

3x 12AX7

Gain

462 dB MC, 42 dB MM (measured at tape output)

Frequency Response

RIAA +/- .25 dB

Channel Seperation

> 70dB @ 1 kHz

Maximum Input

Infinite signal (attenuation precedes the gain circuitry)

MC Load Impedance

selectable, 470, 300, 250, 200, 150, and 100 ohms

MM Load Impedance

selectable, 47k, 30k, 25k, 15k, and 10k ohms
100pF

Overload

117MV @ 1kHz = 8 volts RMS output; 460MV @ 10kHz

Residual Noise

Less than 3MV at output (s/n ratio greater than approx. 69db
